    Plastic Vacuum Automatic Loading Machine Hopper Loader with Environmental Color

    Ask Lasest Price
    Brand Name : ORSTE
    Model Number : OAL-S
    Certification : CE, ISO, SGS
    Price : USD 400 ~ 4000 per Set
    Payment Terms : TT, LC, Paypal, West Union, Cash
    Supply Ability : 500-3000 Sets / Year
    Delivery Time : 7-15 days
    • Product Details
    • Company Profile

    Plastic Vacuum Automatic Loading Machine Hopper Loader with Environmental Color

    Plastic Vacuum Automatic Loading Machine Hopper Loader with Environmental Color

    NAMING PRINCIPLE

    OAL- xxS

    ① ②

    ① Orste Auto-Loader

    ② Motor Power (HP)

    S: Separate Type

    FEATURES

    • Microprocessor for ease of use and accurate control.
    • Stainless hopper receiver ensures no material contamination.
    • Motor overload protector ensures long service life of motor.
    • OAL-S loaders adopts stainless steel mesh thus avoids damage to the motor.
    • For OAL-S series, auto dust-removing device is standardly equipped which saves labor cost for cleaning of filters and expand the lifespan of the machine.
    • Complete safety protection function device, like electricity indicator, phase-reversing alarm, material shortage and motor overloading alarm.
    • Both micro-switch hopper (OVH) and photo-sensor hopper (OPH) can be directly mounted on the feed port of molding machine.

    FUNCTIONAL SCHEME

    The control device starts the vacuum motor to take out the air in the hopper, the material valve is closed meanwhile, thus negative pressure is created. With the function of negative pressure, material in the storage tank is delivered to the hopper through material pipe. The vacuum motor stops working when the suction time comes out, the material valve is opened by material, then material falls into injection machine or other equipment.


    PARAMETERS

    ModelMotor PowerConveying Capacity (kg/hr)Motor TypeVertical Conveying Height (m)Horizontal Distance (m)PowerHopper Capacity (L)
    kwhp
    OAL-1.5S1.11.5200Carbon Brush Type47.51ф, 230VAC, 50/60Hz7.5
    OAL-1S0.751300Induction Type483ф, 400VAC, 50/60Hz7.5
    OAL-2S1.52350Induction Type7207.5
    OAL-3S2.253420Induction Type9.5507.5
